Mochi

A soft-body companion character, and the engine that draws her.

---

She is an ovoid whose widest point sits at 0.295 of her height, formed from superellipse exponents 1.86 above the waist and 2.58 below. She squashes without changing area, leans by a shear pinned at the point where she meets the surface, breathes on a one-sided curve and settles on an underdamped spring. Her face rides on her at a grip of 0.82 — following the body without looking printed on.

Every image in this file was rendered by the package itself, from MOCHI. There is no second drawing of her anywhere in this repository for the code to drift away from.

Zero runtime dependencies.

npm install mochi-avatar

From a plain HTML page

<script type="module">
  import 'mochi-avatar/element'
</script>

<dough-avatar emotion="happy" style="width: 200px; height: 200px"></dough-avatar>

That is the whole integration. The element makes its own canvas, sizes it at device resolution, runs the frame loop, and stops when it leaves the document.

Attributes: emotion (one of the eight below), size (a percentage or fit-canvas), face (a FaceSpec as JSON). Removing an attribute resets it.

Against a canvas

import { DoughAvatar } from 'mochi-avatar'

const avatar = new DoughAvatar(canvas.getContext('2d'), { size: 'fit-canvas' }) // Mochi by default
avatar.resize(300, 300, devicePixelRatio)
avatar.setEmotion({ emotion: 'happy', intensity: 1 })

const tick = (now) => {
  avatar.render(now)
  requestAnimationFrame(tick)
}
requestAnimationFrame(tick)

She is alive before you tell her anything

That image is not a loop somebody animated. It is the engine, running, with no input at all — because an idle character who holds perfectly still reads as a crashed one. She is breathing, and blinking about once every seven seconds — which is her own schedule, not a decision made in the picture. What is turned off there is the sway: setDrift(false), because a still on a page should hold its frame.

Breath	3400ms, one-sided. Two half raised-cosines meeting at zero slope, 1:1.5 in to out — inspiration is muscular, expiration is elastic recoil. It only ever spreads her; her resting silhouette is a floor she returns to, never a midpoint.
Blink	130ms, 35% closing and 65% opening, because a real lid shuts faster than it opens. Gaps come from a clamped exponential — blinking is a Poisson process, and a uniform gap reads as a metronome within about thirty seconds.
Drift	Three mutually incommensurate sines per channel, so the pattern never visibly repeats. About 2.6px of sway on a 94px body: somebody shifting their weight, not somebody pacing.

All of it is a pure function of the clock — no timers, no random walk, no state that a throttled tab can desynchronise. Ask it where she is at time t and it answers.

Making her do things

avatar.setEmotion({ emotion: 'happy', intensity: 1 })
avatar.playMotion('hop') // nod · sway · hop · swing · turn · wander
avatar.lookAt(0.4, -0.2) // she follows a point; the far side wraps out of sight
avatar.poke() // squash, then settle on the spring
avatar.setAsleep(true) // she keeps breathing; stopping entirely reads as a crash

Speaking

avatar.setSpeaking(true)
avatar.setMouthOpen(0.8) // drive this from your audio, per frame
avatar.setSpeaking(false)

EnvelopeMouth in core/mouth will do the driving for you from an audio envelope — advanceEnvelope turns a Float32Array of samples into a mouth opening with attack and release, so speech does not chatter on every zero crossing.

Two honest limits: setVisemes exists on the backend interface but this rig does not implement it — the mouth is one lens with an opening, not a phoneme shape, and caps.visemes says so rather than pretending. And the custom element wires emotion, size and face only; anything above needs the JS object.

Accessibility

avatar.setReducedMotion(true) // stops the idle motion, keeps one-shot replies
avatar.setDrift(false) // stops only the sway; she goes on breathing

setReducedMotion is the accessibility preference, and it stops the breath along with everything else. setDrift is the weaker, orthogonal one: use it when she has to hold a fixed frame but should still look alive — which is exactly what the image at the top of this page is doing. A companion who answers nothing is a picture, not a quieter companion — the preference asks for less movement, not for no feedback.

Expressions

_{neutral · happy · shy · sad · angry · surprised · thinking · sleepy}

Each is a set of multipliers on the neutral geometry rather than separate artwork, so one silhouette carries all eight. Sleepy has no mouth on purpose — a mouth left on a sleeping face reads as awake-but-quiet.

Colourways

_{matcha · sakura · kinako · yuzu · ramune · budo}

import { mochiIn, MOCHI } from 'mochi-avatar'
const sakura = mochiIn('sakura', MOCHI)

One geometry throughout — five colour fields swapped, nothing else. Which is the claim the picture is making: she is the shape, not the colour.

Just the geometry

core is pure arithmetic. It returns points and numbers, and imports no canvas, no document and no platform — useful for hit-testing, your own renderer, or working out where to put something.

import { domeOutline, squashed, widthAt } from 'mochi-avatar'

const shape = {
  halfWidth: 50,
  height: 78,
  waist: 0.295,
  upperShoulder: 1.86,
  lowerShoulder: 2.58,
  lean: 0,
}
domeOutline(shape) // the closed outline, as points
widthAt(shape, 0.5) // half-width at half height, 0..1
squashed(shape, 0.2) // area-preserving

Where it runs

Target	How
Browser	canvas.getContext('2d')
Worker	OffscreenCanvas
Node	@napi-rs/canvas or node-canvas
No canvas at all	core only, or the SVG emitter

CanvasRenderingContext2D is used structurally, so no adapter is needed. The conformance test has been rendering her under Node this whole time.

Making your own character

A face is data, not code — see FaceSpec. A design is a JSON file, and the format bounds every field so a bad one is refused with a reason instead of rendering something wrong in a way nothing mentions.

import { DoughAvatar, PLAIN } from 'mochi-avatar'
new DoughAvatar(ctx, { face: { ...PLAIN, waist: 0.5, colBody: '#c88e9d' }, size: 'fit-canvas' })

PLAIN is a deliberately generic body — a near-symmetric egg, one flat tone, no blush — built to be visibly a different creature from her along the axes that identify her. It exists to be started from.

Give no face at all and you get Mochi, since that is whose package this is.

Example: Mochi as a Codex CLI pet

examples/codex-pet/ exports her as a sprite atlas — 74 frames, no canvas and no frame loop, because the core is pure functions and does not need either. Six colourways are prebuilt, so installing one is a copy into ~/.codex/pets/.

It is also the closest thing to a fidelity test this package has. Re-pointed at the published build, 73 of its 74 frames came out pixel-identical to an atlas produced against the original application's source tree — and the six flavours have pixel-identical alpha channels, which is the "same shape, five fields swapped" claim measured rather than asserted.

Licence

Two licences, split by directory. The engine is MIT. Mochi herself — src/characters/ — is not: use her as she is, in anything including what you sell, but don't rename her, sell her as the goods, or make her your brand. The full terms are short and in LICENSE.md; the reasoning is in BRAND.md.

If you want a character of your own, the engine is all you need.

The desktop app has been retired

Mochi began as a realtime-voice AI companion that lived on your macOS desktop. That app is no longer developed.

• Downloads still work. Every release remains available, including v0.1.20 with signed and notarized builds for Apple silicon and Intel.
• The source is preserved on the archive/app branch, exactly as it was at v0.1.20.
• No further releases will be published here, so installed copies will go on reporting themselves up to date rather than trying to update into a package.

The character outlived the application, which is the usual way round.
